| Attribute | Description |
|---|---|
| RoHS Status | ROHS3 Compliant |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| REACH Status | REACH Unaffected |
| ECCN | AR99 |
| HTSUS | 8541.49.1050 |
| Product Attribute | Attribute Value |
| Manufacturer: | Osram Opto Semiconductor |
| Product Category: | Laser Diodes |
| Output Power: | 75 W |
| Wavelength: | 905 nm |
| Color: | Infrared |
| Vf - Forward Voltage: | 9 V |
| Minimum Operating Temperature: | - 40 C |
| Maximum Operating Temperature: | + 85 C |
| Package / Case: | T-1 3/4 |
| Brand: | OSRAM Opto Semiconductors |
| Characteristic Temperature: | - |
| Differential Efficiency: | - |
| Fall Time: | 1 ns |
| Height: | 5 mm |
| If - Forward Current: | 40 A |
| Length: | 5.9 mm |
| Product Type: | Laser Diodes |
| Rise Time: | 1 ns |
| Series Resistance: | - |
| Factory Pack Quantity: | 50 |
| Subcategory: | Lasers |
| Supply Voltage - Max: | - |
| Supply Voltage - Min: | - |
| Type: | Pulsed Laser Diode |
| Vr - Reverse Voltage: | 3 V |
| Width: | 5.1 mm |
| Part # Aliases: | Q62702P5353 Q62702P5353 |
| Unit Weight: | 0.008501 oz |
