| Attribute | Description |
|---|---|
| RoHS Status | RoHS non-compliant |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| REACH Status | REACH Unaffected |
| ECCN | AR99 |
| HTSUS | 8501.10.4040 |
| Type | Description |
|---|---|
| Category | Motors, Actuators, Solenoids and DriversStepper Motors |
| Mfr | Analog Devices Inc. |
| Series | PANdrive™ |
| Package | Bulk |
| Product Status | Active |
| Type | Hybrid |
| Coil Type | Bipolar |
| Voltage - Rated | 4.17VDC |
| Current Rating (Amps) | 2.8 A |
| Steps per Revolution | 200 |
| Step Angle | 1.8° |
| Accuracy | ±5% |
| Torque - Holding (oz-in / mNm) | 438.99 / 3100 |
| Size / Dimension | Square - 2.362 x 2.362 (60.00mm x 60.00mm) |
| NEMA Frame Size | 24 |
| Diameter - Shaft | - |
| Length - Shaft and Bearing | - |
| Mounting Hole Spacing | - |
| Termination Style | Wire Leads with Connector |
| Operating Temperature | -20°C ~ 50°C |
| Coil Resistance | 1.5 Ohms |
| Features | Integrated Controller, Flatted Shaft |
| Rotor Inertia | 840gcm² |
| Approval Agency | - |
| Base Product Number | PD60-4 |
