Note: Lead time, stocks, and price may differ based on the time and availability with supplier.
| Attribute | Description |
|---|---|
| RoHS Status | ROHS3 Compliant |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) |
| REACH Status | REACH Unaffected |
| ECCN | EAR99 |
| HTSUS | 8542.39.0001 |
| Type | DescriptionSelect All |
|---|---|
| Category | Power Supplies - Board MountDC DC Converters |
| Mfr | Texas Instruments |
| Series | SIMPLE SWITCHER® |
| Package | Tape & Reel (TR) |
| Product Status | Obsolete |
| Type | Non-Isolated PoL Module |
| Number of Outputs | 1 |
| Voltage - Input (Min) | 6V |
| Voltage - Input (Max) | 20V |
| Voltage - Output 1 | 0.8 ~ 6V |
| Voltage - Output 2 | - |
| Voltage - Output 3 | - |
| Current - Output (Max) | 10A |
| Applications | ITE (Commercial) |
| Features | UVLO |
| Operating Temperature | -40°C ~ 125°C |
| Efficiency | 92% |
| Mounting Type | Surface Mount |
| Package / Case | TO-PMOD-11, Power Module |
| Size / Dimension | 0.59" L x 0.59" W x 0.23" H (15.0mm x 15.0mm x 5.9mm) |
| Supplier Device Package | - |
| Base Product Number | LMZ12010 |
