Note: Lead time, stocks, and price may differ based on the time and availability with supplier.
| Type | Description |
|---|---|
| Category | Integrated Circuits (ICs) |
| Embedded | Microcontrollers |
| Mfr | NXP USA Inc. |
| Series | MPC5xx |
| Package | Tray |
| Product Status | Not For New Designs |
| Matkronics Programmable | Not Verified |
| Core Processor | PowerPC |
| Core Size | 32-Bit Single-Core |
| Speed | 56MHz |
| Connectivity | CANbus, EBI/EMI, SCI, SPI, UART/USART |
| Peripherals | POR, PWM, WDT |
| Number of I/O | 56 |
| Program Memory Size | 1MB (1M x 8) |
| Program Memory Type | FLASH |
| EEPROM Size | - |
| RAM Size | 36K x 8 |
| Voltage - Supply (Vcc/Vdd) | 2.5V ~ 2.7V |
| Data Converters | A/D 40x10b |
| Oscillator Type | External |
| Operating Temperature | -40°C ~ 125°C (TA) |
| Mounting Type | Surface Mount |
| Package / Case | 388-BBGA |
| Supplier Device Package | 388-PBGA (27x27) |
| Base Product Number | MPC565 |
