Note: Lead time, stocks, and price may differ based on the time and availability with supplier.
| Attribute | Description |
|---|---|
| RoHS Status | ROHS3 Compliant |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| REACH Status | REACH Unaffected |
| ECCN | EAR99 |
| HTSUS | 8531.80.9041 |
| Type | Description |
|---|---|
| Category | Audio Products - Alarms, Buzzers, and Sirens |
| Mfr | CUI Devices |
| Series | CPS |
| Package | Box |
| Product Status | Active |
| Driver Circuitry | Indicator, Internally Driven |
| Input Type | DC |
| Voltage - Rated | 24 V |
| Voltage Range | 12 ~ 25V |
| Frequency | 3.5kHz |
| Technology | Piezo |
| Operating Mode | Warble |
| Sound Pressure Level (SPL) | 95dB @ 24V, 100cm |
| Current - Supply | 100mA |
| Port Location | User Defined |
| Operating Temperature | -20°C ~ 70°C |
| Mounting Type | Bracket Mount |
| Termination | Wire Leads |
| Size / Dimension | 1.772 L x 1.575 W (45.00mm x 40.00mm) |
| Height - Seated (Max) | 2.335 (59.30mm) |
| Base Product Number | CPS-5952 |
