| Attribute | Description |
|---|---|
| RoHS Status | ROHS3 Compliant |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| REACH Status | REACH Unaffected |
| ECCN | EAR99 |
| HTSUS | 8531.80.9041 |
| Type | Description |
|---|---|
| Category | Audio Products - Alarms, Buzzers, and Sirens |
| Mfr | CUI Devices |
| Series | CPI |
| Package | Tape & Reel (TR), Cut Tape (CT), Digi-Reel® |
| Product Status | Active |
| Driver Circuitry | Indicator, Internally Driven |
| Input Type | DC |
| Voltage - Rated | 12 V |
| Voltage Range | 3 ~ 15V |
| Frequency | 4kHz |
| Technology | Piezo |
| Operating Mode | Single Tone |
| Duration | - |
| Sound Pressure Level (SPL) | 95dB @ 12V, 10cm |
| Current - Supply | 12mA |
| Port Location | Top |
| Operating Temperature | -40°C ~ 85°C |
| Approval Agency | - |
| Ratings | - |
| Ingress Protection | - |
| Mounting Type | Surface Mount |
| Termination | Solder Pads |
| Size / Dimension | 0.870 Dia (22.10mm) |
| Height - Seated (Max) | 0.295 (7.50mm) |
| Base Product Number | CPI-2207 |
